BG CFFRSW818SPD 22 Module 18 Way Fully Recessed, 80A 30mA RCD, 1xSPD & 1x32A MCB
SKU CFFRSW818SPD
Availability:
SOLD OUT
Sold out
Original price
£84.99
-
Original price
£84.99
Original price
£84.99
Inc VAT
£70.83
Exc VAT
£84.99
-
£84.99
Current price
£70.83
£70.83
-
£70.83
Current price
£70.83
BG 22 Module 18 Way Fully Recessed, 80A 30mA RCD, 1xSPD & 1x32A MCB
- Lockable cover option available
- Easy access of cables via knockouts, in sides top and bottom, plus additional rear entry knockouts
- Spirit level, to enable quick installation
- Backed-out and retained terminal screws, prevents loss of screws, and saves on installation time
A method of installation which allows the installer to carry out a first fix to a property, without the worry of other trades painting or plastering the outer front cover. This range also offers a smaller profile for narrow passages and where height requirements are specified. Available in Main Switch/RCD, Dual RCD, in Populated and Unpopulated versions.
This item is 18 Way Fully Recessed with 80A RCD, SPD + 32A MCB
Features
- This range of consumer units are designed to be fully recessed into a wall or cavity up to a depth of 68mm
- Amendment 3 Compliant
- If the installation is being completed to Part M of the building regulations then the consumer units should be mounted between 1350mm and 1450mm above floor level
- Each cover has capability for barrel lock installation and is fitted with cover lock blank as standard
- The CUA15 barrel lock is available separately
Circuit Protection Range Leaflet:
Click Here for Circuit Protection Range Leaflet
