BG CFFD8614ASPD 22 Module 14 Way Fully Recessed Unpopulated + 100A Switch, 1x80A, 1x63A Type A 30mA RCD, 1xSPD & 1x32A MCB
SKU CFFD8614ASPD
Availability:
SOLD OUT
Sold out
Original price
£111.68
-
Original price
£111.68
Original price
£111.68
Inc VAT
£93.07
Exc VAT
£111.68
-
£111.68
Current price
£93.07
£93.07
-
£93.07
Current price
£93.07
BG 22 Module 14 Way Fully Recessed Unpopulated + 100A Switch, 1x80A, 1x63A Type A 30mA RCD, 1xSPD & 1x32A MCB
- Lockable cover option available
- Easy access of cables via knockouts, in sides top and bottom, plus additional rear entry knockouts
- Spirit level, to enable quick installation
- Backed-out and retained terminal screws, prevents loss of screws, and saves on installation time
A method of installation which allows the installer to carry out a first fix to a property, without the worry of other trades painting or plastering the outer front cover. This range also offers a smaller profile for narrow passages and where height requirements are specified. Available in Main Switch/RCD, Dual RCD, in Populated and Unpopulated versions.
This item is 14 Way Fully Recessed with 1 X 63A 1 X 80A TYPE A RCD, SPD + 32A MCB
Features
- This range of consumer units are designed to be fully recessed into a wall or cavity up to a depth of 68mm
- Amendment 3 Compliant
- If the installation is being completed to Part M of the building regulations then the consumer units should be mounted between 1350mm and 1450mm above floor level
- Each cover has capability for barrel lock installation and is fitted with cover lock blank as standard
- The CUA15 barrel lock is available separately
Circuit Protection Range Leaflet:
Click Here for Circuit Protection Range Leaflet
