Saxby 120341 OrionRGBW 48V 11.5W/m IP20 LED Strip 4000K - 30m

The Saxby 120341 OrionRGBW 48V LED Strip is a versatile flexible lighting solution combining RGB colour capability with a dedicated 4000K cool white output. This combination makes it ideal for installations where dynamic coloured lighting and practical white illumination are required from the same LED tape.

Supplied as a generous 30-metre roll, the OrionRGBW operates at 48V and consumes 11.5W per metre. Its SMD 5050 LED technology delivers up to 8,850 lumens across the complete roll, providing a flexible solution for accent, feature, task and decorative lighting.

The tape can be cut and joined to accommodate different installation layouts, making it suitable for bespoke residential and commercial lighting schemes. With a maximum continuous run length of 15 metres, it is particularly useful for larger projects requiring extended runs of RGBW LED lighting.

Key Features

• Flexible RGBW LED strip for versatile indoor lighting
• RGB colour capability with dedicated 4000K cool white light
• 48V operating voltage
• 11.5W per metre power consumption
• Supplied as a 30m roll
• Maximum continuous run length of 15m
• Up to 8,850 lumens across the complete 30m roll
• SMD 5050 LED technology
• IP20 rated for suitable dry indoor environments
• Flexible construction for easy cutting, joining and installation
• Slim 10mm-wide profile
• Ideal for accent, task, feature and decorative lighting

Specification

• Brand: Saxby
• Product Code: 120341
• Range: OrionRGBW
• Product Type: RGBW Flexible LED Strip
• Voltage: 48V
• Power Consumption: 11.5W/m
• Total Wattage: 345W
• LED Type: SMD 5050
• White Colour Temperature: 4000K Cool White
• Total Light Output: 8,850 Lumens
• Luminous Efficacy: 26lm/W
• IP Rating: IP20
• Maximum Continuous Run: 15m
• Roll Length: 30m
• Height: 2mm
• Width: 10mm
• Material: Polymer Film
• Colour: White
• Electrical Class: Class III

Applications

Ideal for residential, retail, hospitality and commercial interiors where both coloured effects and functional 4000K white illumination are required. Typical applications include coving, cabinetry, shelving, retail displays, architectural features and decorative lighting installations.

Please Note: The 30m roll has a maximum continuous run length of 15m. This LED strip is IP20 rated for suitable dry indoor locations. A compatible 48V driver, RGBW controller and any required connection accessories should be selected separately.

Data Sheet:

Click Here for Data Sheet
