Ovia OEO15-ME Evo Orb 10W/13W/15W IP65 CCT LED Bulkhead with Emergency & Microwave Sensor – White

The Ovia OEO15-ME Evo Orb LED Bulkhead combines intelligent microwave sensing, emergency lighting and flexible output control in one robust fitting. Designed for commercial, communal and general lighting applications, it offers selectable wattage, adjustable colour temperature and dependable emergency operation.

The integrated microwave sensor provides automatic occupancy-based lighting control, helping to reduce unnecessary energy consumption. Sensor settings can be adjusted using DIP switches, while the available corridor function provides additional flexibility for circulation areas, stairwells, corridors and communal spaces.

For emergency lighting applications, the OEO15-ME incorporates a maintained emergency pack. The emergency system can be configured between standard and Self-Test Emergency modes by selecting the appropriate position on the driver, providing convenient control from a single fitting.

Integrated power-switchable technology allows the bulkhead to operate at 10W, 13W or 15W, enabling installers to select the required output to suit the application without changing the luminaire.

The built-in CCT selector provides three colour temperature options: 3000K warm white, 4000K neutral white and 6000K daylight/cool white. This makes the Evo Orb suitable for a wide range of lighting environments and installation requirements.

With an IP65 rating and IK08 impact resistance, the OEO15-ME is designed for durable performance in demanding environments. It also aligns with standard BESA box spacing for straightforward mounting, while push-fit terminals help make wiring quicker and easier.

Four M20 gland entry points provide flexible cable entry options, with additional knockouts incorporated into the bezel to accommodate glands where required.

Key Features & Benefits

• Integrated adjustable microwave motion sensor
• Microwave sensor configuration using DIP switches
• Corridor function for flexible lighting control
• Maintained emergency lighting pack
• Selectable standard or Self-Test Emergency operation
• Selectable 10W, 13W or 15W power output
• Selectable 3000K, 4000K or 6000K colour temperature
• IP65 rated for protection against dust and water
• IK08 rated for enhanced impact resistance
• Push-fit terminals for quick and convenient wiring
• Designed to align with standard BESA box spacing
• Four M20 gland entry points for flexible cable installation
• Additional bezel knockouts for gland entry
• Durable white finish

Specification

• Brand: Ovia
• Range: Evo Orb
• Product Code: OEO15-ME
• Wattage: 10W / 13W / 15W selectable
• Colour Temperature: 3000K / 4000K / 6000K selectable
• Sensor: Microwave
• Sensor Adjustment: DIP switches
• Corridor Function: Yes
• Emergency: Maintained emergency pack
• Emergency Modes: Standard / Self-Test selectable
• IP Rating: IP65
• Impact Rating: IK08
• Terminal Type: Push-fit
• Cable Entry: 4 x M20 gland entry points
• Finish: White

Data Sheet:

Click Here for Data Sheet
