FuseBox MAFDD100630B 6A 1P+N Switched B Curve 10kA 30mA Type A Mini AFDD RCBO

Product Description

The FuseBox MAFDD100630B is a compact 6A B Curve Mini AFDD RCBO designed to provide comprehensive electrical circuit protection within a single DIN rail device. Combining arc fault detection, overcurrent protection and 30mA Type A residual current protection, it helps protect electrical installations against multiple types of potentially dangerous faults.

Designed for modern electrical installations, the MAFDD100630B continuously analyses the circuit waveform to identify both series and parallel arc faults. If a potentially hazardous arc fault is detected, the device automatically disconnects the affected circuit to help reduce the risk of electrical fires.

Its compact single-module design helps maximise available space within compatible consumer units and distribution equipment, while clear LED indication assists with quick fault identification and troubleshooting.

Key Features & Benefits

• 6A rated Mini AFDD RCBO
• B Curve tripping characteristic
• 1P+N switched configuration
• 10kA short-circuit breaking capacity
• 30mA Type A residual current protection
• Combines arc fault, overcurrent and residual current protection in one device
• Detects both series and parallel arc faults by analysing the circuit waveform
• Automatically disconnects the affected circuit when a hazardous arc fault is detected
• Compact single-module design helps save valuable DIN rail space
• Clear LED indication supports fast and straightforward fault finding
• Suitable for use in modern residential, commercial and other appropriate electrical installations

Product Specifications

• Brand: FuseBox
• Product Code: MAFDD100630B
• Product Type: Mini AFDD RCBO
• Rated Current: 6A
• Curve: B Curve
• Configuration: 1P+N Switched
• Breaking Capacity: 10kA
• Residual Current Rating: 30mA
• RCD Type: Type A
• Mounting: DIN Rail
