Emlite ECA2.Z Single Phase Energy Meter 100A with Extended Terminal Cover

Product Description

The Emlite ECA2.Z Single Phase Energy Meter is a compact and reliable metering solution designed for installations where available space is limited. With a maximum current rating of 100A and an extended terminal cover included, it is suitable for a wide range of domestic and commercial energy metering applications.

The ECA2.Z accurately measures active electrical energy (kWh) in both import and export directions. Energy readings are clearly displayed on the large, easy-to-read LCD screen, which can be configured to automatically cycle through available registers or remain fixed on a selected register.

An integrated optical communications port allows electronic meter readings and configuration using a compatible probe and software. Designed for long-term reliability, the meter incorporates solid brass cable terminals for dependable operation at currents up to 100A, together with reverse energy fraud detection and tamper-resistant construction.

Key Features

• Compact single phase electricity meter
• Maximum current rating of 100A
• Extended terminal cover included
• MID approved for compliant energy metering applications
• EN 50470-1 and EN 50470-3 Class B accuracy
• Measures active energy (kWh) in both import and export directions
• Large, easy-to-read LCD display
• Configurable automatic register cycling or static display
• Optical communications port for meter reading and configuration
• Reverse energy fraud detection
• High-quality solid brass cable terminals
• Designed for reliable long-term operation

Technical Specification

• Brand: Emlite
• Model: ECA2.Z
• Meter Type: Single Phase Energy Meter
• Voltage Range: 220-240V
• Maximum Voltage: 267V
• Maximum Current: 100A
• Energy Measurement: Import and Export Active Energy (kWh)
• Accuracy: Class B (1%)
• Display: LCD
• Protection Rating: IP52
• Certified Product Life: 20 Years
• Terminal Cover: Extended Cover Included
