Ansell APAC1/60/2 Pace UGR<19 600x600 Backlit LED Panel CCT Multi Wattage 20W / 26.5W / 30W 3000K / 4000K / 6500K

Product Description

The Ansell APAC1/60/2 Pace 600x600 Backlit LED Panel is a versatile, high-performance lighting solution designed for education, commercial and ancillary applications. Combining a slimline 595 x 595mm profile with efficient backlit LED technology, it is ideal for installations where ceiling void space is limited.

Featuring UGR<19 glare control, the Pace panel helps improve visual comfort in working and learning environments. Integrated CCT and wattage selection allows installers to choose between 3000K, 4000K or 6500K colour temperatures and 20W, 26.5W or 30W power settings from a single luminaire, providing greater flexibility on site.

Delivering up to 3800 lumens at 4000K with an efficacy of up to 130lm/W, the APAC1/60/2 provides efficient, uniform illumination. SDCM 3 colour consistency helps minimise visible variations in white tones across multiple luminaires, making it particularly suitable for larger installations.

Key Features

• 600x600 backlit LED panel for education, commercial and ancillary applications
• UGR<19 design helps reduce glare and improve visual comfort
• Selectable wattage: 20W, 26.5W or 30W
• Selectable colour temperature: 3000K, 4000K or 6500K
• Delivers up to 3800 lumens at 4000K
• High efficiency of up to 130lm/W at 4000K
• Slimline 34mm depth is suitable for shallow ceiling voids
• SDCM 3 colour consistency for uniform white tones
• TPa rated as standard
• IP44 rated
• 90° symmetrical beam distribution
• Compatible with self-test panel pod or sensor pod
• Dimmable and OCTO options available
• Switch Dim, DALI and 1-10V dimming available when used with compatible ADDIM/30/MC multi-dimmable driver accessories
• Suitable for recessed, ceiling and suspended mounting applications

Dimensions

• Length: 595mm
• Width: 595mm
• Depth: 34mm

Specification

• Brand: Ansell Lighting
• Product Range: Pace
• Product Code: APAC1/60/2
• Product Type: Backlit LED Panel
• Colour / Finish: White
• Materials: Aluminium, PS and steel
• Wattage: 20W / 26.5W / 30W selectable
• Colour Temperature: 3000K / 4000K / 6500K selectable
• Delivered Lumens: 2700-3800lm at 4000K
• Luminous Efficacy: Up to 130lm/W at 4000K
• UGR: <19
• CRI: 80
• Beam Angle: 90°
• Light Distribution: Symmetrical
• IP Rating: IP44
• Protection Class: Class II
• Emergency: No
• Mounting Options: Ceiling, recessed or suspended
• Application: Internal
• Input Voltage: 220-240V
• Frequency: 50/60Hz
• Operating Temperature: -20°C to +40°C
