Ansell ALUP/2/WH/DD1 Luppa CCT XPRESS IP66 23W Dimmable LED Bulkhead White 3000K/4000K

The Ansell ALUP/2/WH/DD1 Luppa CCT XPRESS LED Bulkhead is a robust 23W dimmable luminaire designed for education, commercial, industrial and demanding indoor or outdoor applications. Finished in white, it features a durable die-cast aluminium body with an opal polycarbonate diffuser for reliable and evenly distributed illumination.

Operating at 23W with a selectable 3000K or 4000K colour temperature, the Luppa provides flexibility to select warm white or cool white light to suit the application. The range delivers between 1750 and 3200 lumens at 4000K, with an efficiency of up to 140lm/W.

This DD1 version is mains (Triac) dimmable, allowing the light output to be adjusted when used with a compatible dimming control. This makes it suitable for installations where adjustable light levels are required.

With an IP66 ingress protection rating and IK08 impact resistance, the fitting is suitable for demanding internal and external environments. Installer-friendly features include a gear tray positioned on the diffuser, removable conduit entries and discreet side and top cable entry points for quick and straightforward installation.

Key Features

• 23W LED bulkhead
• Selectable 3000K or 4000K colour temperature
• Mains (Triac) dimmable
• Up to 3200 lumens delivered at 4000K
• Efficiency of up to 140lm/W at 4000K
• IP66 rated for demanding indoor and outdoor applications
• IK08 impact resistance
• Die-cast aluminium body with opal polycarbonate diffuser
• 107° symmetrical beam distribution
• CRI 80 colour rendering
• Removable eyelid trim design
• Integrated LED board switch allows the section behind the eyelid to be deactivated for improved energy efficiency
• Gear tray located on the diffuser for quick and simple installation
• Removable conduit entries on the base
• Discreet side and top conduit entry points
• Tamper-proof stainless steel Allen key screws
• Suitable for ceiling, surface and wall mounting

Specification

• Product Code: ALUP/2/WH/DD1
• Range: Luppa CCT XPRESS
• Colour / Finish: White
• Material: Aluminium and polycarbonate
• Wattage: 23W
• Lumens Delivered: 1750lm - 3200lm at 4000K
• Efficiency: 135lm/W - 140lm/W at 4000K
• CCT: 3000K / 4000K selectable
• CRI: 80
• Beam Angle: 107°
• Distribution: Symmetrical
• Dimmable: Yes
• Dimming Type: Mains (Triac)
• Emergency: No
• IP Rating: IP66
• IK Rating: IK08
• Protection Class: Class I
• Input Voltage: 220-240V
• Frequency: 50/60Hz
• Operating Temperature: -20°C to +40°C
• Mounting: Ceiling, surface or wall
• Application: Internal / external

Dimensions

• Diameter: 298mm
• Depth: 99mm

Applications

Ideal for schools, corridors, communal areas, commercial premises, industrial buildings, entrances and external walkways where a durable IP66 LED bulkhead with mains dimming and selectable colour temperature is required.

Data Sheet:

Click Here for Data Sheet
