LIVE Electrical SPV240 2 Pole 20kA/40kA Type 2 DC Surge Protection Device
Live Electrical SPV240 2-Pole 20kA/40kA Type 2 DC Surge Protection Device
Product Overview
The Live Electrical SPV240 2-Pole Type 2 DC Surge Protection Device (SPD) provides reliable protection against transient overvoltages in DC power and solar photovoltaic (PV) systems. Designed for high-performance protection up to 1000VDC, the SPV240 safeguards sensitive components and equipment from surge damage caused by lightning strikes or electrical switching events.
Built with high-energy varistors and integrated thermal disconnect technology, this SPD ensures fast response and safe operation during fault conditions. Its plug-in protection module allows for quick installation and easy maintenance, while optional remote signalling supports monitoring in larger installations. Compliant with IEC/EN 61643-31 standards, the SPV240 is a robust and dependable choice for DC surge protection in renewable and industrial systems.
Key Features & Benefits
- Type: Type 2 DC SPD – ideal for solar and DC power applications.
- Poles: 2-pole configuration for 1000VDC circuits.
- Nominal discharge current (In): 20kA.
- Maximum discharge current (Imax): 40kA.
- Max continuous operating voltage (Uc): 1300VDC.
- Voltage protection level (Up): ?4.0kV.
- Response time: <25 nanoseconds for rapid surge suppression.
- Thermal disconnector: Provides fault indication for enhanced safety.
- Protection class: IP20 enclosure rating.
- Operating temperature: -40°C to +80°C.
- Mounting: Plug-in module for simple installation and replacement.
- Standards: Fully compliant with IEC/EN 61643-31 and BS EN 61643-31.
Applications
- Solar photovoltaic (PV) arrays and inverters
- Battery energy storage systems (BESS)
- Industrial and renewable DC systems
- Telecoms and off-grid installations
