Schneider Electric GGBL4001S Lisse White Moulded 45A DP Cooker Control Unit with 13A Socket & LED (Display Packaged)
SKU GGBL4001S
Availability:
IN STOCK
Original price
£18.40
-
Original price
£18.40
Original price
£18.40
Inc VAT
£15.33
Exc VAT
£18.40
-
£18.40
Current price
£15.33
£15.33
-
£15.33
Current price
£15.33
Schneider Electric GGBL4001S Lisse White Moulded 45A DP Cooker Control Unit with 13A Socket & LED (Display Packaged) (Display Packaged)
Product DescriptionLED indicator Angled terminals for easier access Backed out and captive screw terminals to allow for a positive drive and speed of installation Screw cap covers provided for a sleek finish
Specifications- Range: Lisse
- aesthetic name: White moulded
- Product or component type: Cooker control unit
- device presentation: Complete product
- Outlet standard: British
- Colour tint: white Complementary:
- Rated current: 45 A at 230 V AC 50 Hz
- Number of gangs: 2 gang
- Pilot light: LED
- Fixing mode: By screws M3.5 x 30 mm
- Connections - terminals: Screw terminals
- Material: Urea (carbamide)
- Type of installation: Indoor
- Depth: 32.8 mm
- width: 148.5 mm
- Height: 87 mm
- Net weight: 0.235 kg Environment:
- Standards: BS 4177
- IP degree of protection: IP20
Data Sheet:
Click Here for Data Sheet
