LIVE Electrical LSMC06SRN/100 6 Way Metal Populated SRN Consumer Unit with 100A Main Switch, SPD & RCBOs

The LIVE Electrical LSMC06SRN/100 is a high-quality 6 way metal consumer unit designed for efficient and reliable circuit protection in domestic and light commercial installations. Supplied pre-populated, this unit includes a 100A double pole main switch, an integrated 20/40kA surge protection device (SPD), and 3 x double pole Type A RCBOs for enhanced safety and compliance.

Engineered for ease of installation, this consumer unit features a streamlined internal layout, integrated busbar system and fly-lead-free RCBOs, helping to minimise wiring time and maintain a neat finish. Flexible cable entry points, including rear access, provide added convenience for installers.

Populated Devices

• 1 x 6A RCBO – RNC106B-030N
• 1 x 20A RCBO – RNC120B-030N
• 1 x 32A RCBO – RNC132B-030N
• 100A double pole main switch
• 20/10kA double pole surge protective device – SP140 1P+N/2

Key Features

• 6 way metal populated SRN consumer unit
• Suitable for surface-mounted installations
• Supplied with 100A double pole main switch
• Integrated 20/40kA surge protection device for added safety
• Pre-installed Type A B curve double pole RCBOs
• Fly-lead-free RCBO design for a cleaner, more organised installation
• Integrated live and neutral busbar for faster wiring
• Clean internal layout for easy inspection, testing and maintenance
• Flexible cable entry options including rear access
• Supplied with neutral cable, busbar, neutral and earth terminals, DIN rail and cable gland
• Modular busbar system allows future circuit expansion

Dimensions

172 x 270 x 110mm (H x W x D)

Additional Information

Designed with practicality in mind, this surge protected consumer unit offers a compact yet robust solution for modern electrical installations. Its pre-populated configuration reduces installation time while maintaining a professional and compliant setup.
