LIVE Electrical CB363D Triple Pole 63A D Curve 10kA MCB

Name: LIVE Electrical CB363D Triple Pole 63A D Curve 10kA MCB
Brand: LIVE Electrical
SKU: CB363D
Price: 11.22 GBP
Availability: InStock

LIVE Electrical CB363D Triple Pole 63A D Curve 10kA MCB

Availability:

IN STOCK

SKU CB363D

£13.93

£13.93 - £13.93

£13.93

£9.35

Exc VAT

£11.22

Inc VAT

£11.22 - £11.22

£11.22

£9.35 - £9.35

£11.22

Product Description

Customer Reviews

LIVE Electrical CB363D Triple Pole 63A D Curve 10kA MCB

Product Description

Triple Pole Miniature Circuit Breakers (MCB) 10kA

Features:

Rated current In (A) :63
Poles: 3P.
Rated voltage Ue(AC): 230/400V.
Rated frequency: 50/60Hz.
Insulation volage Ui: 500V.
Rated breaking capacity(A): 10kA.
Rated impulse withstand voltage(1.2/50) Uimp (V): 4000.
Dielectric test voltage at ind. Frq for 1 min (kV) : 2.
Ambient temperature(with daily average ?35 °C?-5~+40).
Thermo-magnetic release characteristic: D.
Electrical life: 8,000.
Contact position degree: IP20.
Storage temperature( °C)?-25~+70).
Reference temperature for setting of thermal element ( °C)?30.
Cable terminal capacity maximum?16mm².

LIVE Electrical Catalogue:

Click Here for LIVE Electrical Catalogue:

Product Description

LIVE Electrical CB363D Triple Pole 63A D Curve 10kA MCB

Product Description

Triple Pole Miniature Circuit Breakers (MCB) 10kA

Features:

Rated current In (A) :63
Poles: 3P.
Rated voltage Ue(AC): 230/400V.
Rated frequency: 50/60Hz.
Insulation volage Ui: 500V.
Rated breaking capacity(A): 10kA.
Rated impulse withstand voltage(1.2/50) Uimp (V): 4000.
Dielectric test voltage at ind. Frq for 1 min (kV) : 2.
Ambient temperature(with daily average ?35 °C?-5~+40).
Thermo-magnetic release characteristic: D.
Electrical life: 8,000.
Contact position degree: IP20.
Storage temperature( °C)?-25~+70).
Reference temperature for setting of thermal element ( °C)?30.
Cable terminal capacity maximum?16mm².

LIVE Electrical Catalogue:

Click Here for LIVE Electrical Catalogue:
