LIVE Electrical CB350D Triple Pole 50A D Curve 10kA MCB
Product Description
Triple Pole Miniature Circuit Breakers (MCB) 10kA
Features:
- Rated current In (A) :50
- Poles: 3P.
- Rated voltage Ue(AC): 230/400V.
- Rated frequency: 50/60Hz.
- Insulation volage Ui: 500V.
- Rated breaking capacity(A): 10kA.
- Rated impulse withstand voltage(1.2/50) Uimp (V): 4000.
- Dielectric test voltage at ind. Frq for 1 min (kV) : 2.
- Ambient temperature(with daily average ?35 °C?-5~+40).
- Thermo-magnetic release characteristic: D.
- Electrical life: 8,000.
- Contact position degree: IP20.
- Storage temperature( °C)?-25~+70).
- Reference temperature for setting of thermal element ( °C)?30.
- Cable terminal capacity maximum?16mm².
