LIVE Electrical CB163D Single Pole 63A D Curve 10kA MCB

Name: LIVE Electrical CB163D Single Pole 63A D Curve 10kA MCB
Brand: LIVE Electrical
SKU: CB163D
Price: 3.64 GBP
Availability: InStock

LIVE Electrical CB163D Single Pole 63A D Curve 10kA MCB

Availability:

Dispatch in 2-5 Days

SKU CB163D

£4.53

£4.53 - £4.53

£4.53

£3.03

Exc VAT

£3.64

Inc VAT

£3.64 - £3.64

£3.64

£3.03 - £3.03

£3.64

Product Description

Customer Reviews

LIVE Electrical CB163D Single Pole 63A D Curve 10kA MCB

Product Description

Single Pole Miniature Circuit Breakers (MCB) 10kA

Features:

Rated current In (A) :63
Poles: 1P.
Rated voltage Ue(AC): 230/400V.
Rated frequency: 50/60Hz.
Insulation volage Ui: 500V.
Rated breaking capacity(A): 10kA.
Rated impulse withstand voltage(1.2/50) Uimp (V): 4000.
Dielectric test voltage at ind. Frq for 1 min (kV) : 2.
Ambient temperature(with daily average ?35 °C?-5~+40).
Thermo-magnetic release characteristic: D.
Electrical life: 8,000.
Contact position degree: IP20.
Storage temperature( °C)?-25~+70).
Reference temperature for setting of thermal element ( °C)?30.
Cable terminal capacity maximum?16mm².

LIVE Electrical Catalogue:

Click Here for LIVE Electrical Catalogue:
