LIVE Electrical CB116D Single Pole 16A D Curve 10kA MCB

Name: LIVE Electrical CB116D Single Pole 16A D Curve 10kA MCB
Brand: LIVE Electrical
SKU: CB116D
Price: 3.04 GBP
Availability: InStock

Availability:

Dispatch in 2-5 Days

SKU CB116D

£3.89

£3.89 - £3.89

£3.89

£3.04

Inc VAT

£2.53

Exc VAT

£3.04 - £3.04

£2.53

£2.53 - £2.53

£2.53

Product Description

Customer Reviews

LIVE Electrical CB116D Single Pole 16A D Curve 10kA MCB

Product Description

Single Pole Miniature Circuit Breakers (MCB) 10kA

Features:

Rated current In (A) :16
Poles: 1P.
Rated voltage Ue(AC): 230/400V.
Rated frequency: 50/60Hz.
Insulation volage Ui: 500V.
Rated breaking capacity(A): 10kA.
Rated impulse withstand voltage(1.2/50) Uimp (V): 4000.
Dielectric test voltage at ind. Frq for 1 min (kV) : 2.
Ambient temperature(with daily average ?35 °C?-5~+40).
Thermo-magnetic release characteristic: D.
Electrical life: 8,000.
Contact position degree: IP20.
Storage temperature( °C)?-25~+70).
Reference temperature for setting of thermal element ( °C)?30.
Cable terminal capacity maximum?16mm².

LIVE Electrical Catalogue:

Click Here for LIVE Electrical Catalogue:

Product Description

LIVE Electrical CB116D Single Pole 16A D Curve 10kA MCB

Product Description

Single Pole Miniature Circuit Breakers (MCB) 10kA

Features:

Rated current In (A) :16
Poles: 1P.
Rated voltage Ue(AC): 230/400V.
Rated frequency: 50/60Hz.
Insulation volage Ui: 500V.
Rated breaking capacity(A): 10kA.
Rated impulse withstand voltage(1.2/50) Uimp (V): 4000.
Dielectric test voltage at ind. Frq for 1 min (kV) : 2.
Ambient temperature(with daily average ?35 °C?-5~+40).
Thermo-magnetic release characteristic: D.
Electrical life: 8,000.
Contact position degree: IP20.
Storage temperature( °C)?-25~+70).
Reference temperature for setting of thermal element ( °C)?30.
Cable terminal capacity maximum?16mm².

LIVE Electrical Catalogue:

Click Here for LIVE Electrical Catalogue:
