Product Description

The Sync Energy Flow All-In-One 6kW Hybrid Inverter with 3 Batteries is a high-capacity, fully integrated energy storage system designed for homes with significant electricity demand. Combining a powerful hybrid inverter, modular battery storage and intelligent control into a single stackable unit, it enables maximum use of solar generation while reducing reliance on the grid.

Supplied with three 5.12kWh LiFePO₄ batteries, this configuration delivers a total storage capacity of 15.36kWh with a 90% depth of discharge. The system is PV-ready, allowing solar PV to be added at any time, and the modular design ensures future battery expansion without replacing the inverter.

Smart monitoring and optimisation are handled through the Sync Energy app, giving real-time insight into solar generation, battery usage and grid consumption. With advanced safety features, outdoor-rated protection and silent operation, the Flow system provides a future-proof solution for modern energy management.

Key Features & Benefits

• All-in-one stackable system combining hybrid inverter and battery storage
• 6kW hybrid inverter output for higher power requirements
• Supplied with 3 × 5.12kWh LiFePO₄ batteries (15.36kWh total)
• Modular battery storage expandable up to 35.84kWh
• PV-ready – solar PV systems can be added at any time
• LiFePO₄ battery technology for superior safety and long service life
• Integrated fire suppression for enhanced protection
• Integrated heating for operation below 5°C
• Built-in AC and DC surge protection
• Remote monitoring and control via the Sync Energy smart app
• IP65 ingress protection and IK10 impact resistance
• Silent operation (0 dB)

Dimensions & Weight

• Dimensions (HxWxD): 2400 × 600 × 245 mm
• Total Weight: 201.8 kg

Installation Details

• Installation methods: Wall or ground mounted
• Wall mounting bracket supplied
• Five wall fixing positions
• Three integrated switches
• Nine selective cable entry points
• Screw terminals (Combi) with 6mm² capacity
• Captive and backed-out terminal screws for easier installation
• Two earth terminals
• Fixing screws supplied

Construction & Appearance

• Steel housing with galvanised front finish
• Painted polycarbonate base
• Anthracite Grey finish (RAL 7016)
• Three-module configuration
• Green LED power indicator
• UV stable for long-term outdoor installation

Technical Specifications

• Rated power: 6kW
• Average active efficiency: 97%
• IP rating: IP65
• IK rating: IK10
• Operating temperature range: -25°C to +55°C
• Wi-Fi standards: 802.11 b/g/n
• Wireless protocol: Wi-Fi 2.4 / 5GHz
• Connection type: RS485
• Smart enabled with Sync Energy app
• Meter accuracy: Class C (±2.0%)

Battery Information

• Battery included: Yes (3 modules supplied)
• Battery type: LiFePO₄ (Lithium Iron Phosphate)
• Battery capacity per module: 5.12kWh
• Total battery capacity supplied: 15.36kWh
• Battery weight (per module): 51.1 kg
• Depth of discharge: 90%

Compliance

• WEEE group: 1 (Large household appliances)

Downloads & Resources

Data Sheet:
View the Data Sheet

Instruction Manual:
View the Instruction Manual

BG Sync Energy Flow Catalogue:
View the Catalogue
