Ansell AZLX/1/CW Z LED Linear Opti-X Multi Beam Multi Wattage Black

• Powerful and durable multi-wattage and multi-beam angle surface-mounted IP65 linear high bay, perfect for the demands of all industrial applications, including warehouses, sorting areas, and production facilities.
• Enhanced functionality with two switches, allowing users to adjust the output between 100W, 150W, and 200W and change the angle between four beam angle options: 40x80 / 50x100 / 70x120 /100x120. This adaptability fits perfectly in diverse applications, such as in rented warehouses, where end-users can modify the installation to their specific needs with a simple switch change.
• Versatile installations at different heights possible when utilising the multi-output feature, catering to various racking heights and open areas, thanks to the changeable optic.
• All-in-one solution for multiple projects with just one item to stock, providing cost-efficiency and convenience
• Surface mounting possible with AZPLLED/LC accessory
• 1.5m Suspension kit supplied as standard
• Die-cast aluminium construction provides enhanced thermal performance for longer LED lifespan
• Plug and play microwave sensor option, offering maximum energy saving
• 0/1-10V dimmable as standard (installer must drill through pilot hole and use an IP rated gland on install)

Dimensions

Length:1,108 mm

Height:143 mm

Width:147 mm

Polar Curve

Data Sheet:

Click Here for Data Sheet
