Collingwood GL019RAB40F GL019 0.4W-2.2W IP68 Low Voltage Groundlight, Antique Brass, 38 Degree Beam Angle, 4000K
Collingwood GL019RAB40F 0.4W–2.2W IP68 Low Voltage Ground Light, Antique Brass, 38° Beam Angle, 4000K
Product Description
The Collingwood GL019RAB40F is a high-performance, round low-voltage LED ground light designed for versatility and long-term reliability. Part of the enhanced GL019 modular lighting range, it offers multiple configuration options — including round, square, frosted, low-glare, half-moon, and ultra-low-glare designs — providing flexible solutions for both residential and commercial lighting applications.
Combining discreet aesthetics with powerful light output, this IP68-rated fixture is ideal for illuminating decking, pathways, entrances, and landscape features. The 4000K neutral white colour temperature delivers crisp, clear illumination, while the Antique Brass finish enhances the visual appeal of any installation. Built for durability, it performs flawlessly indoors or outdoors, year after year.
Features & Benefits
- IP68 protection — perfect for both indoor and outdoor use
- Coastal protected — corrosion-resistant design ideal for marine environments
- IK06 impact resistance — suitable for walk-over installations (stainless steel variants rated walk-over)
- Supplied complete with an installation tube for ease of fitting
- Low-voltage LED operation for safety and energy efficiency
- SDCM3 for consistent, uniform light quality
- CRI 80+ ensuring true-to-life colour rendering
- 4000K neutral white for balanced, natural illumination
- Compact yet powerful design with robust outdoor cabling
- Available in a selection of elegant finishes to suit your project
Technical Specifications
| Colour Rendering Index (CRI) | >80 |
|---|---|
| IP Rating | IP68 |
| IK Rating | IK06 |
| Walk Over / Drive Over | Walk Over |
| Tiltable | Fixed |
| Input | 150mA / 250mA / 350mA / 500mA / 700mA DC |
| Ambient Temperature | Up to 55°C |
| Cut-Out Size | 33mm |
| Bathroom Zone | Zone 0 |
| Electrical Class | Class III |
| Suitable for Coastal Areas | Yes |
| Beam Angle | 38° |
| Colour Temperature (CCT) | 4000K |
| Luminous Efficacy | 106–143 lm/W |
| LED Lifetime | L70 70,000 hours |
| Finish | Antique Brass |
| Body Material | Brass |
| Warranty | 7 Years |
| Energy Class | D |
| Luminous Flux | 60–234 lm |
| Power Consumption | 0.4W / 0.7W / 1W / 1.5W / 2.2W |
| Dimensions (W × L × H) | 40mm × 40mm × 41mm |
| Adjustability | Not Adjustable |
| Dimmable | No |
Data Sheet: Download Product Data Sheet
