6243Y 3 Core & Earth PVC 1.5mm Grey Cable - 25m
6243Y 3 Core & Earth PVC 1.5mm² Grey Cable – 25m Drum
Product Overview
The 6243Y 3 Core & Earth 1.5mm² PVC Cable is a high-quality domestic wiring cable designed for higher-load two-way lighting circuits and fixed electrical installations. Suitable for dry or damp environments, it can be safely clipped to surfaces, mounted on trays, or installed in free air where mechanical damage is unlikely. When additional protection is needed, this cable can also be laid within conduit or trunking.
Complying with the BS 6004:2012 standard, the 6243Y cable is BASEC approved, CE marked, and ISO 9001 certified, ensuring quality and reliability. Its flat-profile PVC sheath and copper conductors provide durability, easy handling, and consistent electrical performance, making it ideal for both residential and light commercial applications.
Key Features
- Type: 3 Core & Earth PVC Cable (6243Y)
- Conductor Size: 1.5mm²
- Cable Length: 25m drum
- Application: Suitable for higher-load two-way lighting and general fixed wiring circuits.
- Installation: Can be clipped to surfaces, laid on trays, or enclosed in conduit or trunking for protection.
- Outer Sheath Colour: Grey
- Core Colours: Brown, Black, and Grey (with bare Earth conductor).
- Material: PVC sheath and insulation with copper conductors.
- Cable Profile: Flat, for neat and easy installation.
- Current Rating: 16A
- Resistance: 12.1 Ω/km
- Standard: BS 6004:2012
- Certifications: CE Marked, BASEC Approved, ISO 9001 Certified
Typical Applications
The 6243Y 1.5mm² 3 Core & Earth Cable is perfect for higher-load two-way lighting systems and other fixed wiring installations in domestic or small commercial environments. It offers reliable performance, excellent flexibility, and easy installation for modern electrical systems.
